High shear mixing equipment
380V 50Hz 3P AC voltage
For the manufacturing of pharmacy, daily chemicals, food & beverage industry, especially cosmetic industry such as lipstick, facial cream, lotions, washing detergent, hand sanitizer and ointment.
To dispersing, shearing and cutting force in working load to get uniformly homogenizing and thoroughly emulsifying.
Installed on existing stainless-steel tank, vessel, IBC tote, plastic drum and barrels.
Main parts included in the high shear mixer / homogenizer
| No. | Part name and description | image |
| 1 | the fan for variable speed control motor |  |
| 2 | the driving motor for satisfactory operation under 380V 50hz 3phase AC | |
| 3 | the mounting flange for easy assembly on existing tanks | |
| 4 | the support shafts for working head and driving motor | |
| 5 | the rotation shaft to hold the propeller and rotor | |
| 6 | a down thrust propeller on the main rotation shaft | |
| 7 | the rotor stator assembly (working head) |
Technical specification and price
Model | TRS-2.2V | TRS-4V | TRS-5.5V | TRS-75V | TRS-11V | TRS-15V |
Voltage | 380V 50Hz 3Phase AC | 380V 50Hz 3Phase AC | ||||
Mounting | Top mounting | Top mounting | ||||
Working mode | Batch type | Batch type | ||||
Wet material | Stainless steel 304 | Stainless steel 304 | ||||
Motor poles | 2 | 2 | ||||
Speed | Synchronous RPM 3000 | Synchronous RPM 3000 | ||||
Protection | IP55 | weatherproof enclosures | ||||
Motor power | 2.2kw / 3HP | 4kw / 5.5HP | ||||
Motor mounting type | B5 / B35 | B5 / B35 | ||||
Suitable for | 50~100Liter per cycle | 50~200Liter per cycle | ||||
Working head design | Type B (slotted) | Type C (claw) | ||||
L | 650 | 750 | ||||
M | 165 | 215 | ||||
P | 200 | 250 | ||||
D | 88 | 114 | ||||
D1 | 140 | 180 | ||||
Over length | 1150 | 1250 | ||||
Unit price EXW Wenzhou |
Working heads options for high shear mixers / homogenizer / emulsifying mixer / emulsification mixer / emulsifier.
buyer can choose different working heads for one high shear homogenizer.
TRS series high shear mixer drawing sketch from ranking machinery
