Elliptical Manhole Cover Oval Manway outwards opening for Atmospheric Pressure Vessels

room pressure manway door manhole cover
outwards opening
1.4301 / 06Cr19Ni10 / SUS304 / ASME SS 304
1.4404 / 022Cr17Ni12Mo2 / SUS316L / ASME SS304
Size:
250x350
300x400
350x450
400x500
Material:
stainless steel 304
stainless steel 316
Handle material:
stainless steel
bakelite
Availability:
Quantity:
Inquire Add to Basket

  • TC

room pressure manway door manhole cover, made by stainless steel, outwards opening

1.4301 / 06Cr19Ni10 / SUS304 / ASME SS 304

1.4404 /  022Cr17Ni12Mo2 / SUS316L / ASME SS304


Size

Neck   height

Neck   thickness

Cover   thickness

Max   pre.

250x350

100

2.5

1.5~2.5

<0.1Mpa

300x400

100

2.5

1.5~2.5

<0.1Mpa

350x450

100

2.5

1.5~2.5

<0.1Mpa

430x530

100

3

1.5~2.5

<0.1Mpa

oval manhole is the most simple manway, here are the main parts of it.

manhole cover parts

roon pressure oval type manway door drawing

Oval Elliptical atmospheric manhole cover outwards opening

manway application

manway on milk pasteurizer

manway door on stainlee steel storage tank mixing tank

manhole cover on chemical reactors
