Portable barrel pump for high viscosity liquid (25,000cps) 60lpm

Portable barrel pump for 55 gallon drum, contact part to be stainless steel,
suitable for liquid with viscosity 25,000cps / 25 degree c
KFM, NBR and PTFE seal for stator
220V / 380V voltage

Tube length:
Gasket:
Quantity:
  • HP-0.55KW-25KV
  • ≤ 25,000cps
  • 900rpm
  • 4
  • 2
  • 60lpm
  • 6m
  • 5
Main features

High viscosity barrel pump, portable drum puump, screw type barrel pump,

  • high viscosity sealed design

  • with screw type rotor and stator

  • used for liquids up to 25,000cps / 25 degree c

  • pump tube made by 316L stainless steel

  • Electric motor driven

optional

  • FDA-Compliant materials with tri-clamp connection

  • clamp fittings

  • hose barb

  • customized hanger bracket

Product Description

This portable barrel / drum pump is a hygienic vertical progressive cavity pumps. It is specially designed to transfer high viscosity liquid from tanks and barrels by means of a stainless steel tube placed into the drum.

HP-0.55KW-25KV
Packaging & Shipping

Packing of this barrel pump usually to be paper carton or wooden case according to the shipping method.

usually pumps send by air (TNT, DHL, UPS, FEDEX) will use only oaoer carton to sace the air freight.

but better to use wooden case in order to avoid any damage durign the way.

we do not charge any cost for the wooden case of our drum pumps, but the total weight will increase a lot after packed in wooden case. thus, the air freight will increase accordinly. buyer will need to pay for extra air freight in they choose wooden case for their barrel pump.

Specification

No. Items  Ddescription & specification product pictrue
1 Model HP-0.55KW-25KV
2 Flow rate 60L/min
3 Output pressure 6 bar
4 Motor type electric driven
5 Power supply 110V~415V customized
6 Motor power 550W
7 Potation speed 900 rpm
8 Pump tube 1m (1.2m avaliable under request)
9 Pump tube size φ51
10 Pump tube material Stainless steel 316L
11 Outlet tube φ25 with hose barb
12 Rotor Material Stainless steel 316L
13 Rotor seal material NBR / KFM / PTFE optional
14 Working mode Continuous working

Application



Pumping is characterised by a gentle transfer of media with shear sensitive particles. Some of the most important applications of this pump type is transferring of fruit concentrates for the beverage production, tomato concentrate for the ketchup production, transferring of creams, honey, oils, resins, solvents, adhesives, polymers, gear lube, glycerin and other high viscosity liquid.
